FEATURES:
– Suitable for RC cars 1/10 scale on/off road and 1/8 scale on/off road.
– Programmable/HV Brushless Servo.
– Custom New high power Brushless Motor.
– Supports SR mode with T7PX.
– Programmable and compatible with S.Bus and S.Bus2 systems.
– Can be connected to a PC using the CIU-2/-3 USB adapter sold separately.
– Upper/middle/bottom: Aluminum Case

SPEED:
0.09 sec/60°at 6.0V
0.075 sec/60° at 7.4V

TORQUE:
42.0 kgf/cm at 6.0V
583.3 ozf/in at 6.0V
49.0 kgf/cm at 7.4V
680.5 ozf/in at 7.4V

SIZE:
40.5 mm x 21 mm x 37.8 mm
1.59 in x 0.83 in x 1.49 in

WEIGHT:
76 g
2.68 oz

RATED VOLTAGE:
DC 6.0V-7.4V

OPERATING VOLTAGE:
DC 4.8-8.4V

PowerHD Digital High Voltage RC servo STORM-7
Torque(6.0V): 10.0 kg-cm (138.8 oz/in)
Torque(7.4V): 13.0 kg-cm (180.5 oz/in)
Speed: 0.065 sec (6.0V) │ 0.055 sec (7.4V)
Operating Voltage：6.0 ~ 8.4 DC Volts
Weight: 52.0 g (1.83 oz)
Bearing Type：Ball Bearing x 2
Motor Type：Brushless Motor
Gear Type：Titanium & Steel
Operating Temperature：-20℃~60℃
Working frequence：1520μs / 333hz
Size：41.0 x 20.0 x 26.4 mm ( 1.61 x 0.79 x 1.04 in)

Programmable Car Servo (01102267-3)

SPEED:
0.07 sec/60°at 6.0V
0.06 sec/60° at 7.4V

TORQUE:
20.0 kgf/cm at 6.0V
277.8 ozf/in at 6.0V
24.6 kgf/cm at 7.4V
341.7 ozf/in at 7.4V

SIZE:
40.5 mm x 21 mm x 37.4 mm
1.59 in x 0.83 in x 1.47 in

WEIGHT:
70 g
2.47 oz

RATED VOLTAGE:
DC 6.0V-7.4V

OPERATING VOLTAGE:
DC 4.0-8.4V
